Thermoregulator (temperature controller) DigiTOP TK-5B – is designed to control electric heating systems (TEN, electrode boiler, etc.) with control of supply (Supply), return (Return) and air (Air) temperatures in the heated room with the ability to control the pump mode of the heating system.
€56.10 (€69.00 z VAT)
In stock
Thermoregulator (temperature controller) DigiTOP TK-5B is designed to control electric heating systems (TEN, electrode boiler, etc.) with control of supply (Supply), return (Return) and air (Air) temperatures in the heated room with the possibility of controlling the pump mode of the heating system. Temperature control is achieved by maintaining the set air temperature in the heated room. The use of a thermoregulator allows you to reduce electricity consumption and achieve the most favorable temperature conditions in the heated room.
If necessary, the sensor cable can be extended up to 100 meters using a twisted pair cable.
Compact housing for 3 modules, 6A power supply
To maintain the required temperature, the user sets:
– Maintained temperature,°C
– Hysteresis (AIR, SUPPLY, RETURN)
– Pump operating time
Adjustable temperature range: –55.0… + 125.0 ° C
Mode of operation: Heating
Number of channels: 3
Rated load current: 6A
Maximum load current: 10A
Power supply: AC 230V/50 Hz
Size: 3 modules on DIN rail
| Weight | 69 g |
|---|---|
| Manufacturer | DigiTOP |
Number of measurement channels: 3
Measured temperature range: -55… +125°C
Adjustable temperature range: 0… +85°C
Display discretion: 1 ° C
Dimension error: not more than 0.5 ° C
Temperature hysteresis (Δt): 1…20°C
Maximum load current: 6А
Supply voltage: AC 230V / 50Hz
Power consumption: no more than 3W
Case size (17.5mm modules): 3
Warranty period of 5 years
